What is Single Phase Full Bridge Inverter?

A Single Phase Full Bridge Inverter is a DC to AC inverter that transforms a set DC voltage to an AC voltage. To control the polarity and magnitude of the output voltage, four switches (transistors or thyristors) are connected in an H-bridge configuration. These inverters are commonly utilized in industrial settings, uninterruptible power supplies (UPS), and renewable energy systems.

📌 Specifications of Single Phase Full Bridge Inverter

• The input voltage is typically ranges from 12V to 400V DC.
• This circuit is generated the AC output voltage from 110V or 230V RMS (depending on the application).
• The generated output frequency is ranges from 50 Hz or 60 Hz.
• Switching devices are used here like MOSFETs, Thyristors, and IGBTs as well.
• The efficiency is high around 90% to 97%.
• The output power is depends on the design, typically from a few watts to several kilowatts.

Single Phase Full Bridge Inverter Circuit Diagram

Here is the circuit diagram of Single Phase Full Bridge Inverter –

• Four switching devices (Q1, Q2, Q3, Q4): Connected in H-Bridge configuration.
• DC Source: It is provides the input DC voltage.
• Load: Connected between the output terminals of the bridge.
• Gate Driving Circuit: Controls the switching of transistors or thyristors.

Single Phase Full Bridge Inverter Working

• The inverter operates by turning on and off the switches in a specific sequence to create an alternating output voltage.
• In one half cycle:
  • Q1 and Q4 are turned ON, and Q2 and Q3 are OFF. This applies a positive voltage across the load.
• In the other half cycle:
  • Q2 and Q3 are turned ON, and Q1 and Q4 are OFF. This applies a negative voltage across the load.

Output Voltage Equation

The instantaneous output voltage of a single-phase full bridge inverter is stated as:

• For Square Wave Operation, the output voltage is expressed by –

Where;

1. Vdc = Input DC Voltage
2. ω = Angular Frequency ( ω = 2πf, and f is the output frequency )
3. sgn(sin(ωt)) = Signum function that outputs +1 or -1 depending on the sign of sin⁡(ωt).

• For Pulse Width Modulation Operation or PWM Operation, the output voltage is expressed by –

Where;

• M_a = Modulation Index, which ranges from 0 to 1.
• sin(ωt): Desired sinusoidal output waveform.

Output Current Equation

The current depends on the load connected to the inverter. For pure resistive load, the output current is expressed as –

Where;

• V₀(t) = Output Voltage
• R = Amount of Load

Advantages of Single Phase Full Bridge Inverter

Here are the lists of single-phase full-bridge inverter advantages –

• The output efficiency is high due to low switching losses.
• This circuit is suitable for portable applications.
• It has low harmonic losses.
• The operation of this circuit is both, like bidirectional operation.
• The power ratings can be adjusted by selecting appropriate switches.

Drawback of Single Phase Full Bridge Inverter

Here are the lists of single-phase full-bridge inverter disadvantages –

• The switching of this circuit can generate Electromagnetic Interference (EMI).
• This circuit is requires a gate driver circuit.
• For high power applications, it requires a power cooling system.

Single Phase Full Bridge Inverter Applications

Here we have listed some important applications of this circuit –

• UPS Systems: Supplies AC power during grid outages.
• Industrial Drives: Drives for AC motors and pumps.
• Renewable Energy Systems: Converts DC from solar panels or batteries to AC.
• Electric Vehicles (EVs): Powers AC motors in Electric Vehicles.
• Household Appliances: Powers devices requiring AC from a DC source.
• Telecommunications: Provides reliable power for communication systems.
